Tiltmeter

Name: Tiltmeter
SKU: T500
Availability: InStock

Tiltmeter

The Model 6350 Vibrating Wire Tiltmeter is designed to measure tilt in structures such as buildings, dams and embankments, and also for measurements related to the stability of slopes, open pits, and the walls of excavations (e.g. slurry walls). The tiltmeter is permanently attached to the structure to be monitored and can make measurements on horizontal or vertical surfaces.

Measurement Range

Clear

Select Units

Feet

Meters

Cable Length (+$2.10)

Max length is 30 meters, please enter 30 or less

SKU: T500 Categories: Rotation, Sensors

Accessories

Contact Us With Any Questions

Bridge Diagnostics, Inc. ensures non-discrimination in all programs and activities in accordance with Title VI of the Civil Rights Act of 1964. If you need more information or special assistance for persons with disabilities or limited English proficiency, contact our office at +1.303.494.3230 Ext. 116

Tel +1.303.494.3230

Standard Range¹	±10°
Resolution	±0.05 mm/m (8 arc seconds)
Accuracy²	±0.1% F.S.
Temperature Range¹	−20°C to +80°C
Length x Diameter	194 × 32 mm (transducer only)
